Root Watering System

The Alwasail Root Watering System ensures transplantation survivability, stability in high winds, and fast, healthy growth, especially for trees with deep and broad roots.

Category : New Products,Drippers Devices

Request to Quote

APPLICATION

For young plants and trees to thrive, they must receive adequate irrigation and a steady exchange of oxygen across all levels of the root zone. This encourages roots to grow deep and remain safely below ground, allowing plants to become strong and fully established.

The Alwasail® Root Watering System (RWS) allows vital water, air, and nutrients to bypass compacted soil and directly reach tree and shrub root systems. Its pre-assembled irrigation components facilitate ground installation to depths of 36” (91.4 cm) for the RWS, 18” (45.7 cm) for the RWS-Mini, and 10” (25.4 cm) for the RWS-Supplemental. This system is designed for use with water dispensing devices, such as a bubbler head or an emitter. Users can customize the system to meet their specific irrigation requirements or opt for a version with a pre-installed bubbler.

HOW TO USE IT?

Positioning: Position units evenly spaced, adjacent to the root zone, and within the canopy of the tree.
Filling Canisters: Consider filling canisters with pea gravel to provide better top-to-bottom water dispersion and firmness against root compression.
Dual Perimeters for Long-Term Growth: For promoting long-term deep and broad roots, consider installing two Root Watering System perimeters on separate zones—running the inner zone for the first couple of years and the outer zone in subsequent years.

SPECIFICATIONS

Mesh Material: The sturdy mesh supports the flow of water and air into the root zone and nearby soil.
Pea Gravel Accommodation: The cylinder can be filled with pea gravel, which helps disperse water evenly and prevents root compression.
Integrated Bubbler & Check Valve: These features guide roots away from surfaces and hardscapes, reducing erosion and water waste.
Preconfigured for Easy Installation: The system comes ready to install with swing assemblies or spiral barbed fittings, saving time and ensuring flexibility for different tree and shrub sizes.
Versatile Bubblers: Bubblers on the 18″ (45.7 cm) and 36″ (91.4 cm) models can be swapped out for drip emitters, turning the system into a drip distribution hub.
Drip System Indicator (Optional): An optional indicator can show when the RWS is actively irrigating.
Promotes Healthy Root Growth: The system encourages deep, broad root development, which improves stability during strong winds and supports faster, healthier growth.
Efficient Subsurface Irrigation: Designed to minimize water loss from evaporation and run-off, making irrigation more efficient.
Landscape-Friendly: Installed at ground level, it helps prevent damage to hardscapes and enhances the overall aesthetics of the landscape.
Extra-Wide Collar & Locking Grate: Features a wide collar for easy access to the bubbler and drip line, with a locking grate to prevent vandalism.
Purple Grate & Sock Options: Offers a purple grate for reclaimed water systems and a sock to block small particles from entering the cylinder.
Circumferential Watering Feature: Water flows evenly along the perforated cylinder, ensuring consistent soil moisture along its length.
Dedicated Watering Zone: For best results, install RWS units in their own watering zone to optimize irrigation efficiency and management.

WS-RWS-4B1701-18: Root Watering System with 0.25 GPM (0.9 l/m) bubbler, 4″ (10.2 cm) cap, 18″ (45.7 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-4B1701-36: Root Watering System with 0.25 GPM (0.9 l/m) bubbler, 4″ (10.2 cm) cap, 36″ (91.4 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-4B1702-18: Root Watering System with 0.5 GPM (1.9 l/m) bubbler, 4″ (10.2 cm) cap, 18″ (45.7 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-4B1702-36: Root Watering System with 0.5 GPM (1.9 l/m) bubbler, 4″ (10.2 cm) cap, 36″ (91.4 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-3B1701-18: Root Watering System with 0.25 GPM (0.9 l/m) bubbler, 3″ (9 cm) cap, 18″ (45.7 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-3B1701-36: Root Watering System with 0.25 GPM (0.9 l/m) bubbler, 3″ (9 cm) cap, 36″ (91.4 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-3B1702-18: Root Watering System with 0.5 GPM (1.9 l/m) bubbler, 3″ (9 cm) cap, 18″ (45.7 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.
WS-RWS-3B1702-36: Root Watering System with 0.5 GPM (1.9 l/m) bubbler, 3″ (9 cm) cap, 36″ (91.4 cm) open swing assembly with 1/2″ (15/21) M NPT inlet.

FEATURES

Pressure-compensating bubbler flow rates: Available in 0.9 l/min or 1.9 l/min for precise watering.
Easy swing locking and wide cap design: Provides durable, vandal-proof protection for irrigation hardware and facilitates easy maintenance.
Built-in Alwasail Swing joint: Allows direct installation to a 1/2″ HDPE fitting.
Recommended pressure range: 1.0 to 4.8 bar (100 to 480 kPA).
Investment Protection: Deep and extensive roots promote transplantation success, stability during strong winds, and rapid, healthy growth.
Watering Efficiency: Subsurface irrigation reduces run-off and evaporation.
Landscape Aesthetics: Installs at ground level and helps minimize damage to hardscapes.

BENEFITS

Deep and Broad Roots: Enhance transplantation survivability, ensure stability in high winds, and promote fast, healthy growth.
Subsurface Irrigation: Effectively minimizes run-off and evaporation.
Installation at Grade Level: Helps reduce potential damage to hardscapes.
